CSD Carbonated Beverage Bottle Filler

MODERN XGFD series bottle filler machine is suitable for carbonated beverage filling in plastic bottles with capacity 10000-13000BPH, 200ml-1500ml. This carbonated beverage bottle filler is a unique design machine that combining the three machines of bottle washing, filling and capping in one to decrease power consumption, save space and diminish the air pollution among the three machines.
Availability:
Quantity:
  • XGFD

  • Modern


Carbonated Beverage Bottle Filler Machine

MODERN XGFD series carbonated beverage bottle filler is a unique design machine that combining the three machines of bottle washing, filling and capping in one to decrease power consumption, save space and diminish the air pollution among the three machines.

Carbonated beverage bottle filler


This bottle filler machine is suitable for carbonated beverage filling in plastic bottles with optional capacity.

The suspending bottle-neck conveyor structure makes the bottles stably during the high-speed moving condition, and make changing bottle model more conveniently. HMI (Human machine interface) touch screen and PLC program make it a high degree of automatic production. All parts of the CSD filler machine that have directly contact with the carbonated beverage are made of high quality 304/316 stainless steel. The main electrical components are from international famous companies. such as Mitsubishi Schneider, Siemens.

Carbonated beverage bottle filler(2)

Model

Heads of washing filling capping

Production capacity (Bottle/hour)

Suitable bottle diameter (mm)

Filling temperature (℃ )

Filler type

Filling pressure (MPa)

Motor power (kw)

Overall dimension (LxWxH) (mm)

Weight (kg)

XGFD404010

40-40-10

10000-13000

330-1500ml
  Φ50-Φ110
  H=160-340

0-5

Isobaric filler

0.2-0.4

7.5

4850x3800x2750

8650


Carbonated Beverage Bottling Line

Carbonated Beverage Bottling Line


Manufacturing Process

MODERN manufacture all equipment in our own facilities, which is ECO environment buildings and certified with ISO and CE. MODERN highly concerns environment protection in all working areas by decreasing waste in all production processes.

It takes only two hours driving to the near major shipping seaport SHANGHAI, which provide the most economic shipping rate and fast transportation to most countries all over the world.

Bottle filler manufacturing process


Our facility is composed of the following:

Veteran and skillful professionals and technicians

On-site engineering support

Materials requirement planning (MRP)

Production Engineering

Manufacturing and assembly

Components and machines testing

Hi-tech accurate machining centers


MODERN provide OEM and ODM machines and service tailor designed as per your different needs and goals with the most competitive prices. From individual machines, to turnkey solution service. From idea to real machine, you can expect your quality machines and services which would help to break the limitation of your business.

As a leading manufacturer of bottle filler in China. To keep up with most advanced industry technology and trends, we keep attending all sorts of training and activities.

OEM factory of bottle filler


Tailor Made | Tailored Design Solutions

Customer grows with company expansion, and production line extension as well. MODERN provides optimizing solution with tailored design machinery project to maximize customer’s benefit. Tailor made service covers our whole products range for various projects, with building and customizing automatic packaging systems. Our veteran engineer team will provide evaluation to your products, packaging requirement, and production demands, accordingly design customized equipment for your special needs.


MODERN customized in

Tailored design for equipment

Production processes

Modification and configuration of equipment.


MODERN lead customer in every size and step to a target business.

We are dedicated to customer’s success. Most of our customers return for more machines as their company grows fast and succeeds. No matter from mineral water to carbonated soft drinks, beer, juice, isotonics, tea or liquid dairy products for your current line, multi-station filling line, or a complete turnkey solution filling line, MODERN machinery is tailored to order.

Return custom visiting of filling line
