SPC-BGF
Modern
We - MODERN MACHINERY can supply complete bottle filling solution of edible oil from A to Z, which includs Automatic bottle blowing machine, Automatic bottle filling capping machine, Automatic labeling machine, Automatic carton packaging machine, Automatic palletizer system and the whole factory conveyor system.
This edible oil machine is a automatic filling and capping machine, which is suitable for quantitative filling and capping of all kinds of sauce liquid materials such as vegetable oil, fruit and vegetable sauce, seasoning sauce, granular beverage or fruit juice. This machine has automatic interlocking control of filling cylinder liquid level and feeding, air channel (or screw chain channel conveying) into the bottle, with automatic bottle opening valve filling, cap removal, no bottle no filling, cap removal and other functions.
This oil filling machine has reasonable design, compact structure, convenient operation and maintenance. The main engine adopts frequency conversion and speed regulation, and the operation is stable and reliable. The parts and appearance parts in contact with the materials are made of high-quality stainless steel. After replacing several parts, it can adapt to the quantitative filling of bottles of various specifications.
Bottle Filling part:
Rotary wheel fully made of stainless steel SUS 304.
Plunger piston filling method.
Filling valves are made of SUS304.
Filling valves are reasonably structured with accurate filling.
Bottles go up and down in the function of cam through elevator, to process filling with contact to bottle-mouth.
Filler is driven through gears inside the machine frame.
Bottle Capping part:
Sealing faucet (main part to control the credibility of sealing), is improved by experts with the design of alnico.
Besides the magnetic contortion variation device, there is variation dial which makes variation more easily. The benefit of this design is not only water bottling machine can set the contortion, but also it makes contortion more precise and credible, and reduces inferior. Cap distributing chute is equipped with reverse cap stop and reverse cap pick-out mechanism. Cap distributing chute is equipped with a photocell switch to stop the capper when there is no cap inside the chute. The capper is equipped with inlet bottle detection switch. Centrifugal way of cap arranging is adopted to reduce damage of caps.
A cap inspecting system is applied to control on-off of elevator.
Service
MODERN MACHINERYoffers engineer to assist you in installing your bottling machine. Upon installation of your equipment or line, the engineer stays on-site to watch your new equipment run smoothly and train your operators. Even after our specialist leaves your plant, we are ready to give you timely, courteous service when you need it.
Our engineer offers the following services:
1. Installation of equipment or packaging line at the customer's plant
2. Coordinate schedule with mechanics to perform changeovers and preventive maintenance activities
3. Perform mechanical adjustments (if needed) on equipment and packaging line to optimize equipment's performance
4. Resolve equipment issues
5. Provide on-site training on all assigned procedures
Filling machine machining center
Container loading and shipping
