( Corrugated type) series high speed automatic corrugated folder gluer are using imported electrics and parts , especially for export , able to pre-press the paper and have a better pasting effect , also have a wide application ,this series have features like nice application , high speed , flexible adjustment , big width range . Special for making boxes from flute F , E , C , B ,as wine box , carton box , average speed 8000pcs/hr depends on different box size , this series widely applied to wine factory , carton box factory and the other post reducethe glue waste by two third , it is the perfect product for post-press finishing .
Model | XB |
Linear velocity | 0~220m/min |
Suitable paper quality | 220~800g/m⊃2; cardpaper , B C E F flute paper |
Paste box basic form | One size edge pastes ,two side edge pastes |
Feeding way | Automatically and continuously feeding |
Adhesive | Solute type |
Needed power | 380V 7 KW |
Weight | 3200KG |
Overall Size | 10000*1650(1850)(2050)(2250)(2450)*1300mm |
The scope of Count | 0~999999 |
