We supply complete solution of water Bottle Filling Line from A to Z, which includs Water treatment system, Automatic bottle rinsing filling capping machine, Air dryer, Automatic labeling machine, Automatic bottle packaging machine, Automatic palletizer system and the whole factory conveyor system.
How to deploy mechanical filler sysetm to keep water crystal clear and contaminant free? How to achieve the maximum benefit with speed, accuracy and light weight bottles? Modern Machinery, the expert in bottle water filler machine, will always provide you with the best solution for your products.
New 5L bottle filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are from international famous brand.
This water washing filling capping machine is comprised of rinsing, filling and capping system.
Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling: gravity filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after filling and also control liquid level accurately.
Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.
This jar filling machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size is the same, only the output star wheel needs to be changed if bottles are different. It improves the efficiency a lot.
Product Description
1. for big PET bottle
2. for 3L-10L bottle filling
3. Bottle washing, filling, capping function
For the aim of factory’s big bottle filling .The 5L PET Bottle Filling Machine Includes the washer, filler and capper are in one machine. Smaller and more effective.
For providing a bottle more cleaner and healthier . Washing inside and outside by alkalescent liquid, washing inside and outside by disinfectant water, washing inside and outside by pure water and hot sterile water.
A)Saving the cost: The big bottle filling machine alkalescent liquid and disinfectant water can be cycling used.
B)Easier and safer: The big bottle filling machine washing, filling and sealing pricess is controlled by PLC, and has the safe device for interlock, signal and self-detection.
C)For long life span: The whole automatic jar filling machine is made of the stainless steel 304, with the feature of reasonable structure, easy in operation, it’s the ideal equipment for who want starting or expanding wine producing business.
Bottle Rinsing System:
- Into bottle way is air conveyor direct connection with bottle dial.
- All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean.
- 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.
- 304/316 stainless steel washing pump make the machine more durable
Bottle Filling System:
- 304/316 Stainless steel high precision filling nozzle
- Filling volume adjustable in fine rank, same liquid level after filling
- All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
- 304/316 stainless steel filling pump
- Efficient spray nozzle rinse thoroughly and save water for flushing
Bottle Capping System:
- Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping
- All 304/316 stainless steel construction
- No bottle no capping
- Automatic stop when lack of bottle
- Capping effect is stable and reliable, Defective rate ≤0.2%.
Technical Parameter:
Model | XGF8-8-3 | CGF12-12-4 |
Capacity | 1000BPH | 2000BPH |
Applicable bottle | Plastic bottle 5L-10L Plastic screw cap | |
Applicable filling content | Mineral water, wine, non-carbonated water | |
Washing station | 8 | 12 |
Filling nozzle | 8 | 12 |
Capping head | 3 | 4 |
Main motor power | 3.5kw | 5.5kw |
Water pump power | 0.37kw | |
Dimension (mm) | 2400*2100*2450 | 2800*2250*2450 |
Weight (kg) | 3000 | 4000 |
Service
MODERN MACHINERYoffers engineer to assist you in installing your bottling machine. Upon installation of your equipment or line, the engineer stays on-site to watch your new equipment run smoothly and train your operators. Even after our specialist leaves your plant, we are ready to give you timely, courteous service when you need it.
Our engineer offers the following services:
1. Installation of equipment or packaging line at the customer's plant
2. Coordinate schedule with mechanics to perform changeovers and preventive maintenance activities
3. Perform mechanical adjustments (if needed) on equipment and packaging line to optimize equipment's performance
4. Resolve equipment issues
5. Provide on-site training on all assigned procedures
Filling machine machining center
Container loading and shipping
