We supply complete solution of canning line and packing line from A to Z, which includs Auto can depalletizing machine, Can rinsing device, 2in1 canning machine, Can wraming tunnel/Beer pasteurization tunnel, Air dryer, Automatic bottle packaging machine, Automatic palletizer system, as well as the complete Water treatment system, Mixing tanks, Water chiller, Beverage carbonator and the whole factory conveyor system.
Description:
MODERN MACHINERY beer canning line, whose technology was introduced from SWEDEN, is specially applicable for aluminum can or PET can isobaric filling and seaming for carbonated drink like cola and beer. Capacity of this canning machine is from 2000 to 24000 can per hour, based on 330ml can.
Can is pushed into can holding platform one by one by feeding screw and star-wheel. Centering cup of filler valve will fall to can; the distance between filler valves and cans is sealed by springiness plastic ring. The movement of centering cup is generated by plastic idler wheel along curvilinear motion. After filled, valve will be closed, air is discharged, and centering cup will rise from the can. Filled can will be sent to conveyor chain, then to capper. Capper will take cap, turn over the edge of can and turn the edge to finish the sealing action by the control of cam. After that can is transferred to conveying system.
Can filler Can seamer
Can filling part:
Rotary wheel fully made of stainless steel SUS 304.
Isobaric filling method.
Filling valves are made of SUS304.
Filling valves are reasonably structured with accurate filling.
Bottles go up and down in the function of cam through elevator, to process filling with contact to bottle-mouth.
Filler is driven through gears inside the machine frame.
Link-wheels in rinser, filler and capper are transported in ringed support of bottle-neck
Can seaming part:
This can seaming parts adopts the bottom lifting method with two setps crimp seaming.
Rotary structure with high speed, and easily height adjust.
Model | YGFD24-4 | YGFD30-6 |
Capacity (can/Hour) | 7000-9000 | 12000-15000 |
Suitable can size ( ml ) | 150ml-500ml
| |
Can size | 200/202/206/209
| |
Heads of filling | 24 | 30 |
Heads of sealing | 4 | 6 |
Filling way | Isobaric filling | |
Filling temperature(℃ ) | 0-5℃ | |
Power source specification | AC380V/50HZ | |
Power (kw) | 5.5 | 7.5 |
Overall dimension(mm) | 2800x2200x2350 | 3500x2200x2350 |
Weight(kg) | 4200 | 5000 |
MODERN manufacture all canning line in our own facilities, which is ECO environment buildings and certified with ISO and CE. MODERN highly concerns environment protection in all working areas by decreasing waste in all production processes.
It takes only two hours driving to the near major shipping seaport SHANGHAI, which provide the most economic shipping rate and fast transportation to most countries all over the world.
Veteran and skillful professionals and technicians
On-site engineering support
Materials requirement planning (MRP)
Production Engineering
Manufacturing and assembly
Components and machines testing
Hi-tech accurate machining centers
MODERN provide OEM and ODM canning line and service tailor designed as per your different needs and goals with the most competitive prices. From individual machines, to turnkey solution service. From idea to real machine, you can expect your quality machines and services which would help to break the limitation of your business.
As a leading manufacturer of can filler machine in China. To keep up with most advanced industry technology and trends, we keep attending all sorts of training and activities.
Customer grows with company expansion, and production line extension as well. MODERN provides optimizing solution with tailored design machinery project to maximize customer’s benefit. Tailor made service covers our whole canning line range for various projects, with building and customizing automatic packaging systems. Our veteran engineer team will provide evaluation to your products, packaging requirement, and production demands, accordingly design customized equipment for your special needs.
Tailored design for canning equipment
Production processes
Modification and configuration of equipment.
MODERN lead customer in every size and step to a target business.
We are dedicated to customer’s success. Most of our customers return for more machines as their company grows fast and succeeds. No matter from mineral water to carbonated soft drinks, beer, juice, isotonics, tea or liquid dairy products for your current line, multi-station filling line, canning line or a complete turnkey solution filling line, MODERN machinery is tailored to order.
